General Introduction
A nanosecond continuous wave (CW) green fiber laser is a type of fiber laser that emits a continuous, high-power laser beam in the green wavelength range. It generates pulses that are a few nanoseconds long, enabling it to remove material very accurately and quickly, with minimal damage to the surrounding area. The laser's green wavelength is ideal for processing materials such as copper, gold, and other non-ferrous metals, ceramics, and composites.
Feature:
Medical Implants: The precision and minimal heat effect of Green Lasers make them ideal for creating medical implants that require extreme accuracy, such as stents, pacemaker components, and orthopedic implants.
Microelectronics: Nanosecond CW Green Lasers are perfect for microelectronics manufacturing. When used in conjunction with a microscope, incredibly intricate circuits and features can easily be created on printed circuit boards, semiconductors, and other electronic devices using these advanced Green Lasers.
Jewelry: The precision and accuracy of Green Lasers technology make it ideal for use in the jewelry manufacturing industry. With a nanosecond CW Green Laser, 3D engraving and marking, welding, cutting, and surface texturing can be carried out with ease.
Automotive: Fibre lasers have always played a crucial role in automotive manufacturing. They have become an indispensable tool for the precision cutting of stainless steel parts in the automotive industry, and nanosecond CW Green Lasers afford new levels of precision and efficiency.
Samples:
 |
 |
|
Copper Welding |
Lithium Battery Connector Welding |
 |
 |
|
Copper Welding |
Copper Additive Manufacturing |
 |
 |
|
Lithium Battery – High Power Fuse Welding |
Irregular Material Welding |
| MODE | EO-LIGHT-CW-2-20~450 | ||||
| Average power (W) | 20/30/40 | ||||
| Working mode | Continuous /modulation | ||||
| Maximum modulation frequency(KHz) | 5 | ||||
| Central wavelength(nm) | 532 (±3) | ||||
| Bandwidth 3dB(nm) | <1 | ||||
| Long term power stability(%) | <3 | ||||
| Beam quality( M2) | <1.3 | ||||
| Operating voltage (VAC) | 220V | ||||
| Rated power consumption(kW) | 0.6 | ||||
| Working environment temperature(℃) | 5~35 | ||||
| Cooling mode | water-cooling |
||||
