Product profile

20-120W MOPA Pulse Width Fiber Laser Source, High peak power MOPA laser, peak power >200 kW, single pulse energy 1 mJ, adjustable pulse width from 2 to 50 ns, maintenance-free operation.

Typical Applications: Glass drilling (especially for small holes), surface treatment, laser cutting, laser marking, intelligent mirror paint stripping/matte finishing.

opticial properties

Serial number	parameter name	Parameter Value	unit
1	Central wavelength	1060-1080	nm
2	Spectral width@3dB	<15	nm
3	Maximum peak power	>100	kW
4	Output Power	120	W
5	Power adjustment range	0-100	%
6	Frequency adjustment range	1-3000	kHz
7	On/off light response time	<20	μs
8	Pulse Width	2-50	ns
9	Output power instability	<3	%
10	Beam quality M²	<1.4	/
11	Polarization direction	random	/
12	Is it anti-altitude	Yes	/
13	Indicator (red) optical power	0.3-2	mW
14	Optical diameter	10-12	mm

Electrical properties

Serial number	Parameter name	Parameter Value	Unit
15	Supply voltage	48	VDC
16	Working current	<10	A
17	Power consumption	<480	W
18	Recommended power supply	2600	W

Structural characteristics

Serial number	parameter name	Parameter Value	Unit
26	Machine size	42429670	mm³
27	weight	<13	kg

Pulse width corresponding to power reduction frequency point and maximum single pulse energy

Pulse Width(ns)	Power reduction frequency(kHz)	Frequency Cap(KHz)	Maximum single pulse energy(mJ)
2	500	3000	0.24
5	300	3000	0.40
8	210	3000	0.57
10	150	3000	0.80
12	150	3000	0.80
15	140	3000	0.86
20	130	3000	0.92
30	120	2000	1.00
40	120	2000	1.00
50	120	2000	1.00
